Product Features
Application Area
RoHS REACH LM-80
| Color | DWL(nm) | Lumen(lm) | Current(mA) | Voltage(V) | Ra |
| Red | 619-625 | 17-27 | 200 | 2.0-2.5 | / |
| Green | 522-530 | 35-55 | 180 | 2.9-3.4 | / |
| Blue | 465-470 | 8-15 | 180 | 2.9-3.4 | / |
| White | 6000K | 50-75 | 200 | 2.9-3.4 | 80 |
| White | 5150K | 45-65 | 200 | 2.9-3.4 | 80 |
| Neufral white | 4000K | 40-60 | 200 | 2.9-3.4 | 80 |
| Warm White | 3000K | 35-55 | 200 | 2.9-3.4 | 80 |
RoHS REACH LM-80
| Color | DWL(nm) | Lumen(lm) | Current(mA) | Voltage(V) | Ra |
| Red | 620-625 | 60-75 | 500 | 2.0-2.5 | / |
| Green | 522-530 | 95-125 | 500 | 2.9-3.4 | / |
| Blue | 465-470 | 28-38 | 500 | 2.9-3.4 | / |
| White | 6000K | 105-135 | 500 | 2.9-3.4 | 80 |
| White | 5150K | 90-125 | 500 | 2.9-3.4 | 80 |
| Neufral white | 4000K | 90-115 | 500 | 2.9-3.4 | 80 |
| Warm White | 3000K | 85-115 | 500 | 2.9-3.4 | 80 |
| Amber | 1700-1900K | 65-85 | 400 | 2.9-3.4 | / |
| Lemon | 4030-4280K | 130-165 | 400 | 2.9-3.4 | / |
